Castrol Biobar 46
Castrol BioBar is a range of environmentally acceptable hydraulic fluids formulated from synthetic ester base oils, offering a wide operating temperature range and long service life as a replacement for conventional mineral oils in hydraulic equipment where leakage or spillage could reach the marine environment. Extensively tested for compatibility with standard hydraulic system components, particularly elastomer seals, BioBar allows conversion of existing equipment without major changes. It is recommended for hydraulic systems and hydrostatic transmissions incorporating gear pumps, vane pumps, and radial or axial piston pumps and motors where there is a perceived risk of environmental egress from spillage or leakage.
TECHNICAL SPECIFICATIONS
| Property | BioBar 22 | BioBar 32 | BioBar 46 | BioBar 68 |
| Kinematic Viscosity @ 40°C / 104°F (mm²/s) | 22 | 32 | 46 | 68 |
| Kinematic Viscosity @ 100°C / 212°F (mm²/s) | 4.9 | 6.4 | 8.2 | 11.0 |
| Viscosity Index | 139 | 145 | 147 | 150 |
| Density @ 15°C / 59°F (kg/m³) | 900 | 900 | 920 | 950 |
| Pour Point (°C / °F) | -42 (-43) | -42 (-43) | -36 (-33) | -36 (-33) |
| Flash Point, open cup method (°C / °F) | 226 (438) | 232 (449) | 218 (424) | 230 (446) |
| Rust Test, synthetic seawater (24hrs) | Pass | Pass | Pass | Pass |
| Copper Corrosion (3hrs @ 100°C/212°F) | 1A | 1A | 1A | 1A |
| Foam Sequence I (tendency/stability, ml/ml) | 20/0 | 20/0 | 20/0 | 20/0 |
| Oxidation Stability, Rotating Pressure Vessel test (minutes) | 300 | 300 | 300 | 315 |
KEY FEATURES
| •Reduced environmental impact compared to conventional lubricants: superior biodegradation, significantly reduced bioaccumulation* and toxicity, and enhanced renewability (*using OSPAR criteria for assessing bioaccumulation potential) |
| •Minimal wear of ring and vane in the Vickers PM 104C pump test, contributing to a high level of reliability |
| •Minimal wear of ring and vane in the Eaton-Vickers 35VQ25 pump test, contributing to a high level of reliability |
CLASSIFICATIONS & APPROVALS
| •Tested and registered according to OSPAR (Oslo and Paris Convention for the Protection of the Marine Environment of the North-East Atlantic) requirements |
| •Complies with 2018 US Vessel Incidental Discharge Act (VIDA) criteria for Environmentally Acceptable Lubricants (EALs) |
| •Meets the definition of an Environmentally Acceptable Lubricant (EAL) under the US Vessel General Permit (VGP) 2013 |
Data Sheet Date: 30 Jul 2025
The information contained in this data sheet is based on data considered to be accurate. No warranty is expressed or implied regarding the accuracy of this data. Product specifications and availability are subject to change without notice. Lube Control Pty Ltd accepts no responsibility for any loss or damage arising from the use of this information.
